Spectral Features

Spectral Features#

brainmaze_eeg.features.spectral_features.mean_bands(args)#

Calculate mean power spectral density for each frequency band.

Big Picture: This function computes the average spectral power within specific frequency bands (e.g., delta: 0.5-4 Hz, theta: 4-8 Hz, alpha: 8-12 Hz). These band-specific power measurements are fundamental features in EEG analysis and sleep stage classification, as different brain states are characterized by distinct patterns of oscillatory activity in different frequency ranges.

Technical Details: For each frequency band [f_low, f_high], the mean PSD is calculated as:

\[P_{band} = \frac{1}{N} \sum_{f_i \in [f_{low}, f_{high}]} P(f_i)\]

where N is the number of frequency bins in the band. This provides an absolute measure of power in each band, useful for comparing spectral characteristics across different signals or time segments.

Use Case: Essential for sleep stage classification where: - Delta band (0.5-4 Hz) power increases in deep sleep (N3) - Alpha band (8-12 Hz) power is prominent during relaxed wakefulness - Beta band (12-30 Hz) power increases during active wakefulness - Theta band (4-8 Hz) power is characteristic of light sleep (N1, N2) and REM

Parameters:

args (dictionary) –

  • ‘psd’ (numpy.ndarray[n_samples, n_freq_samples]) - one-sided PSD

  • ’fbands’ (list of lists) - frequency bands in which the feature is to be calculated [[0.5, 4], [5, 9]]

  • ’freq’ (numpy.array[n_freq_samples]) - reference frequency array for the PSD

Returns:

  • x (list(numpy.array)) – List of mean PSD values for each frequency band, one array per band

  • feature_name (list(str)) – Feature names in format ‘MEAN_PSD{low}-{high}Hz’ with the frequencies concatenated directly (e.g., ‘MEAN_PSD0.5-4Hz’) for each band

brainmaze_eeg.features.spectral_features.mean_frequency(args)#

Calculate the mean dominant frequency of the power spectral density.

Big Picture: This function computes the centroid (weighted average) of the frequency spectrum, which indicates where the “center of mass” of the spectral power lies. This is particularly useful in sleep stage classification and EEG analysis to characterize the dominant frequency content of brain activity.

Technical Details: The mean frequency is calculated as the power-weighted average frequency:

\[f_{mean} = \frac{\sum_{i} P(f_i) \cdot f_i}{\sum_{i} P(f_i)}\]

where P(f_i) is the power spectral density at frequency f_i. The calculation is performed over the frequency range defined by the minimum and maximum of the provided frequency bands.

Use Case: Commonly used to distinguish between sleep stages where different frequency bands dominate (e.g., delta in deep sleep vs. alpha/beta in wakefulness).

Parameters:

args (dictionary) –

  • ‘psd’ (numpy.ndarray[n_samples, n_freq_samples]) - one-sided PSD

  • ’fbands’ (list of lists) - frequency bands in which the feature is to be calculated [[0.5, 4], [5, 9]]

  • ’freq’ (numpy.array[n_freq_samples]) - reference frequency array for the PSD

Returns:

  • x (list(numpy.array)) – Calculated mean dominant frequency for each sample

  • feature_name (list(str)) – Feature name: ‘MEAN_DOMINANT_FREQUENCY’

References

MATLAB meanfreq: https://www.mathworks.com/help/signal/ref/meanfreq.html

brainmaze_eeg.features.spectral_features.median_frequency(args)#

Calculate the spectral median frequency of the power spectral density.

Big Picture: The median frequency divides the power spectrum into two equal halves of power. It is the frequency below which 50% of the total power is contained. This metric is robust to outliers and provides an alternative to mean frequency for characterizing the spectral content of signals, especially useful when the power distribution is skewed.

Technical Details: The median frequency f_median is defined as the frequency where the cumulative power reaches 50% of the total power:

\[\int_0^{f_{median}} P(f) df = 0.5 \cdot \int_0^{f_{max}} P(f) df\]

The calculation is performed over the frequency range defined by the minimum and maximum of the provided frequency bands. This implementation uses cumulative sum and finds the crossover point where cumulative power exceeds half the total.

Use Case: Often preferred over mean frequency in EEG analysis when dealing with non-Gaussian spectral distributions or when the presence of high-frequency noise might skew the mean frequency estimate.

Parameters:

args (dictionary) –

  • ‘psd’ (numpy.ndarray[n_samples, n_freq_samples]) - one-sided PSD

  • ’fbands’ (list of lists) - frequency bands in which the feature is to be calculated [[0.5, 4], [5, 9]]

  • ’freq’ (numpy.array[n_freq_samples]) - reference frequency array for the PSD

Returns:

  • x (list(numpy.array)) – Calculated spectral median frequency for each sample

  • feature_name (list(str)) – Feature name: ‘SPECTRAL_MEDIAN_FREQUENCY’

References

MATLAB medfreq: https://www.mathworks.com/help/signal/ref/medfreq.html

brainmaze_eeg.features.spectral_features.non_normalized_entropy(args)#

Spectral entropy (Shannon Entropy)

Parameters:

args (dictionary) –

  • ‘psd’ (numpy.ndarray[n_samples, n_freq_samples]) - one-sided PSD

  • ’fbands’ (list of lists) - frequency bands in which the feature is to be calculated [[0.5, 4], [5, 9]]

  • ’freq’ (numpy.array[n_freq_samples]) - reference frequency array for the PSD

Returns:

  • x (list(numpy.array)) – Calculated features for individual frequency bands

  • feature_name (list(numpy.array)) – Feature names

brainmaze_eeg.features.spectral_features.non_normalized_entropy_bands(args)#

Spectral entropy (Shannon Entropy)

Parameters:

args (dictionary) –

  • ‘psd’ (numpy.ndarray[n_samples, n_freq_samples]) - one-sided PSD

  • ’fbands’ (list of lists) - frequency bands in which the feature is to be calculated [[0.5, 4], [5, 9]]

  • ’freq’ (numpy.array[n_freq_samples]) - reference frequency array for the PSD

Returns:

  • x (list(numpy.array)) – Calculated features for individual frequency bands

  • feature_name (list(numpy.array)) – Feature names

brainmaze_eeg.features.spectral_features.normalized_entropy(args)#

Spectral entropy (Shannon Entropy)

Parameters:

args (dictionary) –

  • ‘psd’ (numpy.ndarray[n_samples, n_freq_samples]) - one-sided PSD

  • ’fbands’ (list of lists) - frequency bands in which the feature is to be calculated [[0.5, 4], [5, 9]]

  • ’freq’ (numpy.array[n_freq_samples]) - reference frequency array for the PSD

Returns:

  • x (list(numpy.array)) – Calculated features for individual frequency bands

  • feature_name (list(numpy.array)) – Feature names

brainmaze_eeg.features.spectral_features.normalized_entropy_bands(args)#

Spectral entropy (Shannon Entropy)

Parameters:

args (dictionary) –

  • ‘psd’ (numpy.ndarray[n_samples, n_freq_samples]) - one-sided PSD

  • ’fbands’ (list of lists) - frequency bands in which the feature is to be calculated [[0.5, 4], [5, 9]]

  • ’freq’ (numpy.array[n_freq_samples]) - reference frequency array for the PSD

Returns:

  • x (list(numpy.array)) – Calculated features for individual frequency bands

  • feature_name (list(numpy.array)) – Feature names

brainmaze_eeg.features.spectral_features.relative_bands(args)#

Calculate relative power spectral density for each frequency band.

Big Picture: This function computes the proportion of total power contained in each frequency band, normalizing by the total power across all bands. Relative power features are more robust to inter-individual differences in overall signal amplitude and better reflect the relative contribution of each frequency band to the overall brain activity. This normalization is crucial for reliable sleep stage classification and cross-subject comparisons.

Technical Details: For each frequency band [f_low, f_high], the relative PSD is calculated as:

\[P_{rel,band} = \frac{\sum_{f_i \in [f_{low}, f_{high}]} P(f_i)}{\sum_{f_i \in [f_{min}, f_{max}]} P(f_i)}\]

where [f_min, f_max] is the continuous frequency interval from the smallest lower bound to the largest upper bound across all provided bands (i.e., f_min = bands.min() and f_max = bands.max()). The sum of all relative band powers equals 1.0, making them interpretable as percentages of total power.

Use Case: Preferred over absolute band powers for machine learning-based sleep staging because: - Accounts for individual differences in EEG amplitude - Reduces the impact of recording conditions (electrode impedance, amplifier gain) - Focuses on the spectral shape rather than absolute magnitude - More stable features across different recording sessions

Clinical Applications: - Sleep stage classification: High relative delta in N3, high relative alpha in wake - Anesthesia depth monitoring: Shifts in relative power distributions - Cognitive state assessment: Changes in relative alpha/beta ratios

Parameters:

args (dictionary) –

  • ‘psd’ (numpy.ndarray[n_samples, n_freq_samples]) - one-sided PSD

  • ’fbands’ (list of lists) - frequency bands in which the feature is to be calculated [[0.5, 4], [5, 9]]

  • ’freq’ (numpy.array[n_freq_samples]) - reference frequency array for the PSD

Returns:

  • x (list(numpy.array)) – List of relative PSD values for each frequency band (values between 0 and 1)

  • feature_name (list(str)) – Feature names in format ‘REL_PSD_{low}-{high}Hz’ (e.g., ‘REL_PSD_0.5-4Hz’) for each band
